An audio video-based multi-modal fusion approach for speech emotion recognition

S M Jishanul Islam1, Sahid Hossain Mustakim1, Musfirat Hossain1, Mysun Mashira1, Nur Islam Shourav1, Md. Rayhan Ahmed1,2, Salekul Islam3 A.K.M. Muzahidul Islam1 Swakkhar Shatabda4
1United International University, 2University of British Columbia, 3North South University, 4BRAC University
Paper (Under Review) Code

Nerfies turns selfie videos from your phone into free-viewpoint portraits.

Abstract

Multi-modal deep learning uses several data modalities, such as text, audio and video. Hence, it emerged as a potential approach to improve the accuracy of predictive systems. This technique has been explored in various tasks, with emotion recognition being particularly notable. However, successful blending of the feature sets generated from the multiple modalities remains a challenging task.

In this paper, we propose a multi-modal architecture for emotion recognition. It effectively combines long-term connections and captures information from both audio and video inputs. Our method utilises a pre-trained R(2+1)D network to process video inputs by effectively capturing the time and space specifics through a combination of 2D and 1D convolutions in a residual learning framework. For audio inputs, several acoustic features such as Root-Mean-Square (RMS), Zero-Crossing Rate (ZCR), Mel-Frequency Cepstral Coefficients (MFCC), and the Mel-Spectrogram averaged along the time domain (Mel) are fed to their audio networks that incorporate 1D CNNs with a Squeeze-and-Excitation (SE) network at the end. These extracted features are combined and passed through a Softmax classifier for emotion prediction.

The proposed model is evaluated on the Ryerson Audio-Visual Database of Emotional Speech and Song (RAVDESS), the Surrey Audio-Visual Expressed Emotion (SAVEE), and the Crowd Sourced Emotional Multimodal Actors Dataset (CREMA-D) datasets. The results demonstrate the effectiveness of our approach, achieving F1 scores of 0.9711, 0.9965, and 0.8990 respectively, competing fairly with the state-of-the-art methods.

Video

Visual Effects

Using nerfies you can create fun visual effects. This Dolly zoom effect would be impossible without nerfies since it would require going through a wall.

Matting

As a byproduct of our method, we can also solve the matting problem by ignoring samples that fall outside of a bounding box during rendering.

Animation

Interpolating states

We can also animate the scene by interpolating the deformation latent codes of two input frames. Use the slider here to linearly interpolate between the left frame and the right frame.

Interpolate start reference image.

Start Frame

Loading...
Interpolation end reference image.

End Frame


Re-rendering the input video

Using Nerfies, you can re-render a video from a novel viewpoint such as a stabilized camera by playing back the training deformations.

Related Links

There's a lot of excellent work that was introduced around the same time as ours.

Progressive Encoding for Neural Optimization introduces an idea similar to our windowed position encoding for coarse-to-fine optimization.

D-NeRF and NR-NeRF both use deformation fields to model non-rigid scenes.

Some works model videos with a NeRF by directly modulating the density, such as Video-NeRF, NSFF, and DyNeRF

There are probably many more by the time you are reading this. Check out Frank Dellart's survey on recent NeRF papers, and Yen-Chen Lin's curated list of NeRF papers.

BibTeX

@article{park2021nerfies,
  author    = {Park, Keunhong and Sinha, Utkarsh and Barron, Jonathan T. and Bouaziz, Sofien and Goldman, Dan B and Seitz, Steven M. and Martin-Brualla, Ricardo},
  title     = {Nerfies: Deformable Neural Radiance Fields},
  journal   = {ICCV},
  year      = {2021},
}
